| Model Name |
DR750X-2CH |
| Channel |
2CH
|
| Highlights |
Full HD (Front + Rear), Cloud, Wi-Fi, GPS, Dual Sony Sensors, External LTE Module
|
| Product Dimensions |
Front: W 118.5 mm (4.67″) x H 36 mm (1.42″) /105 g (3.70 oz)
Rear: W 67.4 mm (2.65″) x H 25 mm (0.98″) / 25 g (0.88 oz)
|
| Rear Camera Connection |
Coaxial cable
|
| Memory Support |
microSD card up to 256GB
|
| Recording Modes |
– Normal,
– Event (Impact Detection / Speed Limit / Manual),
– Parking Mode (Impact+Region-based Motion Detection, Timelapse+Events)
|
| Parking Mode |
YES (with 3-wire hardwiring cable – included)
|
| Parking Mode Event Voice Notifications |
YES
|
| Imaging Sensor |
Front: Sony STARVIS™ CMOS Sensor (Approx. 2.1MP)
Rear: Sony STARVIS™ CMOS Sensor (Approx. 2.1MP)
|
| Viewing Angle |
Front: Diagonal 139°, Horizontal 116°, Vertical 61°
Rear: Diagonal 139°, Horizontal 116°, Vertical 61°
|
| Resolution Frame Rate |
Front / Rear
Full HD @60fps – Full HD @30fps
* Frame rate may vary during Wi-Fi streaming.
|
| Video Codec |
H.264 (AVC)
|
| Image Quality and Bitrate Front/Rear |
Highest (Extreme): 25+10 Mbps
Highest: 12+10 Mbps
High: 10+8 Mbps
Normal: 8+6 Mbps
|
| Format Free |
YES (Adaptive)
|
| Event File Overwrite Protection |
YES (up to 50)
|
| SD Card Failure Alert |
YES
|
| Scheduled Reboot |
YES
|
| Video File Extension |
MP4
|
| Wi-Fi |
Built-in (802.11 b.g.n)
|
| Cloud Compatible |
YES
|
| GPS |
Built-in (Dual Band : GPS, GLONASS)
|
| Microphone |
Built-in
|
| Speaker |
Built-in
|
| Impact Sensor |
3-Axis Acceleration Sensor
|
| LED Indicators |
Front: Recording LED, GPS LED, LTE/Wi-Fi LED, Front Security LED, Proximity Sensing indicator LED
Rear: Rear Security LED
|
| Button |
Button: Wi-Fi ON/OFF (Tap)
Proximity sensor: Mic ON/OFF / Trigger Manual Recording / OFF (configurable)
|
| Operation Temperature |
-20 °C − 85 °C (-4 °F − 185 °F)
|
| Storage Temperature |
-20 °C − 90 °C (-4 °F − 194 °F )
|
| High Temp Cut Off |
Approx. 85 °C (185 °F)
|
| Backup Battery |
Built-in supercapacitor
|
| Input Power |
DC 12V-24V (DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC)
|
| Power Consumption Hour |
Normal Mode (WiFi On / GPS On / 2CH) : 375mA / hour
Normal Mode (WiFi Off / GPS On / 2CH) : 340mA / hour
Parking Mode (WiFi On / GPS Off / 2CH) : 320mA / hour
Parking Mode (WiFi Off / GPS Off / 2CH) : 285mA / hour
* Actual power consumption may vary depending on use conditions and environment.
|
| Certifications |
Front: FCC, CE, RoHS, Telec, WEEE, IC
Rear: FCC, CE, RoHS, WEEE
|
| software |
BlackVue Viewer
* Windows 7 or higher and Mac Yosemite OS X (10.10) or higher
|
| Application |
BlackVue Application (Android 5.0 or higher, iOS 9.0 or higher)
|
| Others |
Adaptive Format-Free File Management System
|
| LTE |
External (optional) |
